Capacity
2000kg
Raised Height
920mm
Lowered Height
100mm
Platform size
1350 x 1000mm
Overview
- Hydraulic hose break protection valves, to prevent uncontrolled platform descent
- Armoured hoses to provide hose damage protection
- Overload protection to ensure the specified maximum capacity only is lifted
- Remote 3 phase, 415v, 50hz power pack as standard. 1 phase 240v available at additional cost
- Low voltage 24v control system to prevent injury
- Water and dust resistant electrical and hydraulic systems – IP54
- Micro-processor controlled for the best reliability
- Mechanical props for safe and secure maintenance
- Chromed, honed, air tested hydraulic cylinders complete with high pressure seals
- All lifts tested to + 30% overload
- Sealed for life, maintenance free bearings
- Scissor arms constructed using steel profiles with torsion bars at points of maximum stress
- Proven designs with over 100,000 lifts in operation
- Aluminium anti-trap safety trip bar mechanism to all sides
- Solid steel pivot blocks, provides strength and stability
- Robust powder coat paint process
- CARRIAGE PRICES PAID*- Mainland UK only, exc Highlands and Islands. Contact us for export carriage prices. Carriage excludes off loading.
Specifications
| Model | Capacity (Kg) | Lift Stroke (mm) | Closed Height (mm) | Raised Height (mm) | Platform Length x Width (mm) | Motor (KW) | Weight incl. pack (Kg) | Lifting Time (Sec) |
|---|---|---|---|---|---|---|---|---|
| TCL 2000 | 2000 | 820 | 100 | 920 | 1350 x 800 | 0.75 | 325 | 24 |
